DY-T940S rim clamping inside 13'-26'

Specifications
Motor power------------------------0.75KW/1.1 KW
Rim Clamping outside-----------12"-24"
Rim Clamping inside-------------13"-26"
Max. tire diameter----------------44”(1120mm)
Max. tire width--------------------14"(355mm)
Power supply----------------------100V-415V,50/60HZ
Rotating speed--------------------6r/min
Working pressure-----------------8-10bar
Bead breaker force---------------2500kg
N.W-----------------------------------330kg
Package size-1150*900*970mm /1145*485*370mm
24 units/20GP 48 units/40GP 48 units/40HQ

EMAIL


Features



1. The new automatic hook of working head, more time-saving, labor-saving.

2. Hand-controlled large shovel structure, patented design.

3. Advanced mechanical arm, the pulley part adopts the setting form, embedded wear-resistant sliding block.

4. All joints of the auxiliary arm are mounted with vertebral bearings, smooth without lag.

5.Three-point compression structure, more stable.

6. Rim clamping inside 28”optional.




Specifications

Motor power-----------------------------0.75KW/1.1 KW

Rim Clamping outside----------------12"-24"

Rim Clamping inside------------------13"-26"

Max. tire diameter----------------------44”(1120mm)

Max. tire width--------------------------14"(355mm)

Power supply---------------------------100V-415V,50/60HZ

Rotating speed-------------------------6r/min

Working pressure---------------------8-10bar

Bead breaker force-------------------2500kg

N.W--------------------------------------330kg

Package size-------------------------1150*900*970mm &1145*485*370mm

24 units/20GP  48 units/40GP   48 units/40HQ
