DY-T910 rim clamping inside 12'-24' tire changer

Specifications
Motor power----------------------0.75KW/ 1.1 KW
Rim Clamping outside---------10"-22"
Rim Clamping inside-----------12"-24"
Max. tire diameter--------------41"(1040mm)
Max. tire width-------------------15”(380mm)
Power supply---------------------100V-415V,50/60HZ
Rotating speed-------------------6r/min
Working pressure---------------8-10bar
Bead breaker force-------------2500kg
N.W--------------------------------240kg
Package size-------------------1130*800*900mm
30 units/20GP 64 units/40GP

EMAIL






Features



1. High strength white steel material, more durable.

2.Thicken working plate and full-aluminum air cylinders.

3. All primary air nozzle fittings are copper fittings.

4. Metal six-square bar pressure cover, beautiful shape, strong and durable, no after-sales service.

5. Thicken the main body and universal breaker with quality protective cover.

6. Optional 26-inch or 28-inch working plate.


Specifications

Motor power----------------------0.75KW/ 1.1 KW

Rim Clamping outside---------10"-22"

Rim Clamping inside-----------12"-24"

Max. tire diameter--------------41"(1040mm)

Max. tire width-------------------15”(380mm)

Power supply---------------------100V-415V,50/60HZ

Rotating speed-------------------6r/min

Working pressure---------------8-10bar

Bead breaker force-------------2500kg

N.W--------------------------------240kg

Package size-------------------1130*800*900mm

30 units/20GP  64 units/40GP
